Non Destructive Testing involves the evaluation of existing structures without causing damage, with the intention of gaining a better understanding of key structural elements. A reliable structural condition assessment with CSI relies on rigorous observations and collecting accurate data so we can adequately describe the existing condition of the structure. Concrete Structure Investigations have award-winning expertise and the resources to provide you with accurate, independent and innovative non-destructive testing. Why you May Need Non-Destructive Testing Scanning is the most frequently used NDT method within CSI, however, there are many others you can find on the CSI website www.csiscan.nz There are links below within concrete elements in order to determine their structural capacity. Scanning is primarily used to determine the estimated size and layout of steel reinforcement within concrete elements in order to help determine their structural capacity. How we do NDT CSI has a wide range of proven NDT techniques, and are award-winning specialists in the non-destructive testing and inspection industry. Our NDT services include (but are not limited to) drossbach investigation, corrosion testing, material testing, low strain impact integrity tests, pull off/shear tests, quality assurance, structural health and monitoring inspections, unreinforced masonry testing, ultrasonic testing and concrete scanning. Ultimate As the name suggests, ultimate tests are carried out until the ultimate strength of the fixing has been reached, and either non-elastic deformation or complete breakage has occurred. Ultimate shear and tensile tests are performed according to British Standard 8539:2012, Section B.2.3.2 - Tests for allowable resistance (statistical approach), using the procedure given in CFA Guidance note: Procedure for site testing construction fixings - 2012. A minimum of 5 shear and 5 tensile tests are performed at each location. Proof- Proof tests are not performed to failure, but instead to a proof load, Np; a specific fraction of the rated loading. Proof tests are performed according to British Standard 8539:2012 Section 3.2 - Tests to validate the quality of installation - Proof tests. The number of fixings to be tested is dependent on the total number to be installed on the job. The standard specifies a minimum of 2.5% or at least 3 fixings per location. If the anchors hold the required load, without movement/deformation/damage to either the fixing anchors themselves or the base material into which they are loaded, they will have met the acceptance criteria. In the event of failure, the number of tests will be doubled within the discrete area of failure. Any questions? Contact the CSI team to find how our non-destructive testing services can help to ensure safe and effective operations of your assets. For More Info: https://csiscan.nz/services/non-destructive-testing/ https://www.yenino.com/nz/company/concrete-structure-investigations-ltd-6023
